Audi Camera Control Unit 4G0907107C – Early Signs of Failure, Fixing and Replacement Guide Camera Control Unit CCU
Modern Audi vehicles like the A7 and A8 (2012–2015 models) are equipped with advanced driver assistance systems, including parking assist and surround-view cameras. At the heart of these systems is the Camera Control Unit (CCU) 4G0907107C / 0275004022, which processes and transmits visual data from multiple cameras to the infotainment system.
If this module starts failing, it can compromise your parking safety and visibility. In this blog, we’ll discuss the early signs of a faulty camera control unit, how to fix it, and a step-by-step replacement guide.
Early Signs of a Faulty Audi Camera Control Unit
-
Blank or Flickering Camera Display: If the reverse camera or surround view suddenly goes black or flickers, it’s a common sign of CCU malfunction.
-
Error Messages: Warnings like Camera System Malfunction or Parking Assist Not Available may appear on the dashboard.
-
Distorted or Frozen Images: The module may struggle to process signals, resulting in frozen or distorted images.
-
Intermittent Operation: The camera system might work occasionally but fail randomly.
-
Failure During Rain or Cold Weather: Moisture or temperature fluctuations can trigger internal faults in the CCU.
How to Fix a Faulty Camera Control Unit
Before replacement, try these steps:
-
Check Wiring & Connections: Loose or corroded connectors can cause signal loss.
-
Inspect for Moisture Damage: The CCU is sensitive to water ingress, especially in trunk or bumper areas.
-
Reset the Control Module: Sometimes, a simple battery disconnect and ECU reset can clear temporary faults.
-
Software Update: Visit an Audi service center for firmware updates that might restore proper function.
-
Repair Services: Specialized ECU repair shops can sometimes refurbish faulty modules.
Replacement Guide for Audi Camera Control Unit (4G0907107C)
If repairs fail, replacing the module is the best solution:
Tools Needed:
-
Trim removal tools
-
Torx screwdrivers
-
Basic socket set
-
Diagnostic scanner (for coding/programming)
Steps to Replace:
-
Locate the CCU: In Audi A7/A8 models, it is usually found in the rear trunk area or near the spare wheel compartment.
-
Disconnect the Battery: Always disconnect the negative terminal to avoid electrical damage.
-
Remove Interior Panels: Use trim tools to carefully remove trunk linings or panels covering the CCU.
-
Unplug Wiring Harness: Release the module connectors gently to avoid damage.
-
Unbolt and Remove the Old CCU: Use the appropriate Torx or socket tool to remove it.
-
Install the New Module: Position the replacement CCU, tighten the bolts, and reconnect the harness.
-
Reassemble Panels & Reconnect Battery.
-
Coding & Calibration: Use ODIS or VCDS diagnostic tools to program the new module to the car's system.
Where to Buy Genuine Audi Camera Control Units?
At Automan Spare Parts, we offer OEM Audi camera control units (4G0907107C / 0275004022) at competitive prices, ensuring quality and reliability.
FAQs
1. Can a faulty CCU be repaired?
Yes, in some cases, specialized electronic repair centers can fix damaged boards or replace faulty components.
2. Does the new CCU require programming?
Yes, the replacement module must be coded and calibrated to work with your car’s cameras.
3. How long does replacement take?
A professional can replace and program the CCU in about 1–2 hours.
